BROAN® Bathroom Exhaust Fan, Series: Flex™ Series, 120 V, 1.2 A, 23.4 W, Ceiling Mounting, 11-1/2 in L x 12-1/8 in W Grille, 4 in Duct, Incandescent Lamp, 100 W Lamp Wattage, Lubricated AC Motor, 110 cfm Rating, 105 sq-ft Coverage Area, 1.3 sones Noise Rating, 9-1/4 in Overall Length, 10 in Overall Width, 5-3/4 in Overall Height, Steel Housing, Galvanized Housing, White Housing, For Use With: Overture™ Connected IAQ System
| Amperage Rating | : | 1.2 A |
| CFM Rating | : | 110 cfm |
| Coverage Area | : | 105 sq-ft |
| Duct Size | : | 4 in |
| Grille Size | : | 11-1/2 in L x 12-1/8 in W |
| Housing Color | : | White |
| Housing Finish | : | Galvanized |
| Housing Material | : | Steel |
| Lamp Type | : | Incandescent |
| Lamp Wattage | : | 100 W |
| Motor Type | : | Lubricated AC |
| Mounting Type | : | Ceiling |
| Noise Rating | : | 1.3 sones |
| Overall Height | : | 5-3/4 in |
| Overall Length | : | 9-1/4 in |
| Overall Width | : | 10 in |
| Power Rating | : | 23.4 W |
| Series | : | Flex™ Series |
| Suitable For Use With | : | Overture™ Connected IAQ System |
| Voltage Rating | : | 120 V |
- Bathroom Exhaust Fan
- 110 cfm, effective ventilation to remove moisture and reduce the risk of mold or mildew in most full baths
- 1.3 sones for quiet performance, enough sound to know your fan is on
- 100 W maximum incandescent A19 type bulb or energy efficient equivalent bulb with maximum overall length of 4.4 in or less (bulb not included)
- Retrofit installations can be done entirely from the room side, no attic access required, this means a faster, easier installation
- EzDuct™ connector can be installed from the room side, with no attic access required
- TrueSeal™ damper technology reduces air leakage up to 50%
- SnapFit flange kit offers flexible installation for new construction or retrofit upgrades
- Foldable mounting ears allow for easy installation in both new construction and room side replacement applications
- UL listed for use over tub or shower when connected to a GFCI protected branch circuit
- Powerful enough for rooms up to 100 sq-ft
- Brighter white grilles blend in to match most common ceiling paint
- Corrosion-resistant galvanized steel housing stands up to moisture
- Permanently lubricated AC motor engineered for continuous operation
