TOTALINE® Multi-Horse Power Direct Drive Blower Motor, 1/2 to 1/6 hp HP Rating, 208 to 230 V, 3.6 A, 60 Hz, 1 ph, 1075 rpm Speed Rating, 4 Speed, Open, 48 Frame, 1.2 in Dia x 5 in L Shaft, Self-Aligning Bearing, Base, Resilient Ring Mount, 104 deg F, For Use With: Exhausts, Air Circulators, Unit Heaters, Unit Coolers
| Amperage Rating | : | 3.6 A |
| Bearing Type | : | Self-Aligning |
| Enclosure Type | : | Open |
| Frame | : | 48 |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1/2 to 1/6 hp |
| Mounting Type | : | Base, Resilient Ring |
| Number of Speeds | : | 4 |
| Phase | : | 1 ph |
| Shaft Size | : | 1.2 in Dia x 5 in L |
| Speed Rating | : | 1075 rpm |
| Suitable For Use With | : | Exhausts, Air Circulators, Unit Heaters, Unit Coolers |
| Temperature Rating | : | 104 deg F |
| Voltage Rating | : | 208 to 230 V |
- Extended thru bolt
- Reversible rotation
- Automatic reset thermal overload protector
- 2-1/4 in resilient rings
- Multi-horse power motors are ideal for truck stock
