ABB IEC Contactor, Model: AF52, 690 VAC, 100 A, 50/60 Hz, 3 hp, 10 hp, 15 hp, 20 hp, 40 hp, 50 hp, 100 to 250 VAC/VDC Coil Voltage, 3 ph Phase, 3 Poles, 690 VAC Contact Rating, 3NO Contact Configuration, DIN Rail Mounting, Screw Terminal, IP Rating: IP20, IP10, 3600 cycles Operating Cycles, -60 to 80 deg C, 125.5 mm Height, 67 mm Width, 111 mm Depth
| Amperage Rating | : | 100 A |
| Coil Power Rating | : | 3 hp, 10 hp, 15 hp, 20 hp, 40 hp, 50 hp |
| Coil Voltage | : | 100 to 250 VAC/VDC |
| Contact Configuration | : | 3NO |
| Contact Rating | : | 690 VAC |
| Depth | : | 111 mm |
| Frequency Rating | : | 50/60 Hz |
| Height | : | 125.5 mm |
| IP Rating | : | IP20, IP10 |
| Model | : | AF52 |
| Mounting Type | : | DIN Rail |
| Number of Auxiliary Contacts | : | 1NO-1NC |
| Number of Poles | : | 3 |
| Operating Cycles | : | 3600 cycles |
| Phase | : | 3 ph |
| Power Rating | : | 3 hp, 10 hp, 15 hp, 20 hp, 40 hp, 50 hp |
| Temperature Rating | : | -60 to 80 deg C |
| Terminal Type | : | Screw |
| Voltage Rating | : | 690 VAC |
| Width | : | 67 mm |
- Can manage large control voltage variations
- Reduced panel energy consumption
- Very distinct closing and opening
- Built-in surge suppression
- Add-on auxiliary contact blocks for front or side-mounting and a wide range of accessories
- Can withstand short voltage dips and voltage sags (SEMI F47-0706 conditions of use on request)
