Ferraz Shawmut Amp-Trap® 2000® Class J Fuse, Series: AJT Series, Indicating/Non-Indicating: Non-Indicating, 600 VAC/500 VDC, 3 A, Class: J, 200 kA Interrupt, 50/60 Hz, Ferrule Terminal, Clip Mount, GMG Body, 2-1/4 in Length, 0.813 in Dia
| Amperage Rating | : | 3 A |
| Body Material | : | GMG |
| Class | : | J |
| Diameter | : | 0.813 in |
| Frequency Rating | : | 50/60 Hz |
| Indicating/Non-Indicating | : | Non-Indicating |
| Interrupt Rating | : | 200 kA |
| Length | : | 2-1/4 in |
| Mounting Type | : | Clip |
| Series | : | AJT Series |
| Terminal Type | : | Ferrule |
| Voltage Rating | : | 600 VAC/500 VDC |
- Non-indicating or solid state SmartSpot visual blown fuse indicator
- Time delay for motor starting and transformer inrush
- Self-certified, UL witnessed tests
- Extremely current limiting for low peak let thru current
- Most current limiting UL class fuse
- Recommended for arc flash energy reduction
- Small footprint requires less mounting space and allows smaller, more economical fuse blocks
- Easy 2-to-1 selectivity for prevention of nuisance shutdowns
- Unique Class J dimensions prevent replacement errors
- High visibility orange label gives instant brand recognition
- Metal embossed date and catalog number for trace ability and lasting identification
- Fiberglass body provides dimensional stability in harsh industrial settings
- High-grade silica filler ensures fast arc quenching
