Lumark Night Falcon™ Rectangular Flood Light, Series: NFFLD, 120 to 277 VAC, 0.466 A, 128 W Wattage, 50/60 Hz, LED Lamp, Glass Lens, 16932 Lumens, 60000 hr Average Life, 0 to 10 V Dimmable Ballast, 4000 K, NEMA 6, IP66 Enclosure, Tempered Lens, Trunnion Mounting, Die Cast Aluminum, Carbon Bronze, Powder-Coated, -40 to 40 deg C, 12-11/16 in H x 15-15/16 in W x 8-11/16 in D, 16/3 SOW Cord
| Amperage Rating | : | 0.466 A |
| Average Life | : | 60000 hr |
| Ballast Type | : | 0 to 10 V Dimmable |
| Color Temperature | : | 4000 K |
| Color | : | Carbon Bronze |
| Cord Size | : | 16/3 SOW |
| Dimensions | : | 12-11/16 in H x 15-15/16 in W x 8-11/16 in D |
| Enclosure Type | : | NEMA 6, IP66 |
| Finish | : | Powder-Coated |
| Frequency Rating | : | 50/60 Hz |
| Lamp Type | : | LED |
| Lens Material | : | Glass |
| Lens Type | : | Tempered |
| Lumens | : | 16932 Lumens |
| Material | : | Die Cast Aluminum |
| Mounting Type | : | Trunnion |
| Series | : | NFFLD |
| Temperature Rating | : | -40 to 40 deg C |
| Voltage Rating | : | 120 to 277 VAC |
| Wattage | : | 128 W |
- Die cast aluminum housing, driver compartment and driver door
- Replaces up to 400 W equivalent metal halide
- 2 Lumens packages, nominal 16900 Lumens and 10500 Lumens
- 6H x 6V NEMA wide distribution, 3H x 3V spot distribution
Instruction/Installation Manual
