ABB AC Drive, 10 hp Motor Output, 50/60 Hz Output, 380 to 480 V Input, 15.6 A Input Current, 3 ph, R3 Frame, IP20, IP66, IP67, 10.91 in L x 9.69 in W x 17.17 in H, Additional Information: 7.5 kW Power Rating, 40 deg C Temperature Rating
| Additional Information | : | 7.5 kW Power Rating, 40 deg C Temperature Rating |
| Amperage Rating | : | 15.6 A |
| Dimensions | : | 10.91 in L x 9.69 in W x 17.17 in H |
| Enclosure Type | : | IP20, IP66, IP67 |
| Frame Size | : | R3 |
| HP Rating | : | 10 hp |
| Input Current | : | 15.6 A |
| Input Voltage | : | 380 to 480 V |
| Motor Output | : | 10 hp |
| Output Frequency Range | : | 50/60 Hz |
| Output Frequency | : | 50/60 Hz |
| Phase | : | 3 ph |
| Power Rating | : | 7.5 kW |
| Temperature Rating | : | 40 deg C |
| Voltage Rating | : | 380 to 480 V |
- The ACS355 drives are designed to meet the requirements of an extensive range of machinery applications in food and beverage, material handling, lifting, textile, printing, rubber and plastics and woodworking applications. The drive is user friendly, yet it provides a wide range of built-in technology such as the safe torque off functionality and sequence programming, reducing the need for additional control electronics. The product offers options and diverse functionality to cater to the needs set for speed and torque control of AC induction and permanent magnet motors.
- Exceptionally compact drives and uniform design
- Quick commissioning with application macros and panel assistants
- Safe torque off function (SIL 3 ) as standard
- Sensorless vector control
- Built-in brake chopper
- High protection class variants for demanding environments
- Permanent magnet and induction motor control
- Torque memory for lifting applications
- Common DC bus
- 600 Hz maximum output frequency
- Sequence programming for controlling state machines without a PLC
