WOODFORD® Freezeless Yard Hydrant, Model: R34, 3/4 in Nominal, 2 ft Bury Depth, FNPT Connection, 57 in Overall Length, 3/8 in Rod Diameter, 125 psi, Ductile Iron Head, Ductile Iron Handle, Steel Rod, 120 deg F
| Bury Depth | : | 2 ft |
| Connection Type | : | FNPT |
| Handle Material | : | Ductile Iron |
| Head Material | : | Ductile Iron |
| Model | : | R34 |
| Nominal Size | : | 3/4 in |
| Overall Length | : | 57 in |
| Pressure Rating | : | 125 psi |
| Rod Diameter | : | 3/8 in |
| Rod Material | : | Steel |
| Temperature Rating | : | 120 deg F |
- All metal construction, no plastic components
- Packing graphite for lubricity and long life
- Valve seat permanent brass valve body with large hemispherical seating surface
- Operation 90 deg handle lift for full on
- 3/4 in brass hose nozzle
- 1 in galvanized steel pipe casing
- 3/8 in steel operating rod
- Adjustable pivot block, provides easy and positive adjustment of the lever lock in tension
- Tamper-proof lock can be padlocked in closed position
