BROAN®, 0.2 A, 11-1/2 in L x 12 in W Grille, 4 in Duct, 50 cfm, 45 sq-ft Coverage Area, 0.5 sones Noise, Housing Finish: Galvanized, White Polymeric Grille, 9-1/4 x 10 x 5-3/4 in Housing, 2 x 6 in Minimum Construction Space Required, Motor Engineered For Continuous Operation, Room Side Installation, 1.11 in L x 1.11 in W x 0.92 in H
| Additional Information | : | White Color Grille |
| Amperage Rating | : | 0.2 A |
| CFM Rating | : | 50 cfm |
| Coverage Area | : | 45 sq-ft |
| Duct Size | : | 4 in |
| Frequency Rating | : | 60 Hz |
| Grille Size | : | 11-1/2 in L x 12 in W |
| Housing Finish | : | Galvanized |
| Housing Material | : | Steel |
| Motor Type | : | AC |
| Mounting Size | : | 2 x 6 in |
| Mounting Type | : | Ceiling |
| Noise Rating | : | 0.5 sones |
| Overall Height | : | 5-3/4 in |
| Overall Length | : | 9-1/4 in |
| Overall Width | : | 10 in |
| Power Rating | : | 20 W |
| Series | : | Flex™ Series |
| Voltage Rating | : | 120 V |
- Compatible with overture connected IAQ system
- 50 cfm, sufficient ventilation to remove odors and pollutants from your smaller powder room or bathroom
- 0.5 sones for ultra quiet performance, you might not notice it's on
- TrueSeal damper technology reduces air leakage up to 50%
- EzDuct connector can be installed from the room side, with no attic access required
- ENERGY STAR® certified for energy efficiency
- UL listed for use over tub or shower when connected to a GFCI-protected branch circuit (ceiling mount only)
- Powerful enough for rooms up to 45 sq-ft
- Brighter white grilles blend in to match most common ceiling paint
- Corrosion-resistant galvanized steel housing stands up to moisture
- Permanently lubricated AC motor engineered for continuous operation
- Optional galvanized steel duct expander for use with 6 in ducting and optional installation brackets are sold separately
- Comparable to NuTone model AEN50
