LS Manual Motor Starter, Series: Metasol Series, 2.5 A, 690 V, 50/60 Hz, 100 kA, 8 kA Interrupt, 3 Pole, 32AF, 1.6 to 2.5 A Trip, Screw Terminal, IP20, 18 to 10 AWG, 18 to 8 AWG Wire, DIN Rail, Screw Mount, 100000 cycles Operating Cycles, -20 to 60 deg C, 45 mm Width, 94 mm Height, Additional Information: 99.6 mm D, Standard Breaking Capacity, Rotary Handle
| Additional Information | : | 99.6 mm D, Standard Breaking Capacity, Rotary Handle |
| Amperage Rating | : | 2.5 A |
| Enclosure Type | : | IP20 |
| Frame Type | : | 32AF |
| Frequency Rating | : | 50/60 Hz |
| Height | : | 94 mm |
| Interrupt Rating | : | 100 kA, 8 kA |
| Mounting Type | : | DIN Rail, Screw |
| Number of Poles | : | 3 |
| Operating Cycles | : | 100000 cycles |
| Series | : | Metasol Series |
| Temperature Rating | : | -20 to 60 deg C |
| Terminal Type | : | Screw |
| Trip Range | : | 1.6 to 2.5 A |
| Trip Type | : | 0 |
| Voltage Rating | : | 690 V |
| Width | : | 45 mm |
| Wire Size | : | 18 to 10 AWG, 18 to 8 AWG |
- New application of MMS-32/63 trip indicator enhances the visibility of trip
- Reinforced breaking reliability compared to existing -MEC MMS
- Same external dimension with -MEC MMS
- Consistency with sol MC by changing appearance color
- Over load
- Short circuit
- Phase failure protection
