| Amperage Rating | : | 200 A |
| Connection Type | : | Triplex Ground |
| Cover Type | : | Ringless |
| Dimensions | : | 4-1/2 in L x 13 in W x 15-1/4 in H |
| Feed Type | : | Side Wireway, Underground |
| Finish | : | Powder-Coated |
| Frequency Rating | : | 60 Hz |
| Hub Type | : | Plain Top |
| Insulation Type | : | Glass Polyester |
| Material | : | Steel |
| Mounting Type | : | Surface |
| NEMA Rating | : | NEMA 3R |
| Number of Jaws | : | 4 |
| Phase | : | 1 ph |
| Terminal Type | : | Lay-In |
| Voltage Rating | : | 600 V |
| Wire Size | : | 6 AWG to 350 kcmil |
