BROAN® Ventilation Fan Light, Series: Flex™ Series, 120 V, 1.2 A, 60 Hz, 75 W, Ceiling Mounting, 7.31 in L x 7.31 in W Grille, 4 in Duct, Incandescent Lamp, 75 W Lamp Wattage, 70 cfm Rating, 65 sq-ft Coverage Area, 1.5 sones Noise Rating, 1 Speed, 8-1/4 in Overall Length, 12-3/4 in Overall Width, 6-7/8 in Overall Height, Steel Housing, White Housing, White Housing
| Amperage Rating | : | 1.2 A |
| CFM Rating | : | 70 cfm |
| Coverage Area | : | 65 sq-ft |
| Duct Size | : | 4 in |
| Frequency Rating | : | 60 Hz |
| Grille Size | : | 7.31 in L x 7.31 in W |
| Housing Color | : | White |
| Housing Finish | : | White |
| Housing Material | : | Steel |
| Lamp Type | : | Incandescent |
| Lamp Wattage | : | 75 W |
| Lumens Wattage | : | 75 W |
| Mounting Type | : | Ceiling |
| Noise Rating | : | 1.5 sones |
| Number of Speeds | : | 1 |
| Overall Height | : | 6-7/8 in |
| Overall Length | : | 8-1/4 in |
| Overall Width | : | 12-3/4 in |
| Power Rating | : | 75 W |
| Series | : | Flex™ Series |
| Voltage Rating | : | 120 V |
- Ventilation Fan Light
- One fan speed
- Motor engineered for continuous operation
- One motor speed
