Fluke® 117 FLUKE 117 In Stock
  1. pin-int

Fluke® 117 FLUKE 117

Electrician's Multimeter, 600 mV, 6 - 600 VDC, 6 - 10 A AC/DC

  • Manufacturer: Fluke
  • Brand Name: Fluke®
  • Part#: FLUKE 117
  • MPN: 117
  • UPC: 095969324205
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading

Fluke® Electrician's Multimeter, 6 to 600 V, 6 to 10 A, 99.99 Hz to 50 MHz, 1000 nF to 1000 uF, 600 Ohm to 40 MOhm Resistance, 2 V Measuring, Backlit LED Display, Alkaline Battery, 0.5%, 1%, 2% Voltage Accuracy, 1%, 1.5% Current Accuracy, 0.9%, 1.5% Resistance Accuracy, 1.9%, 5% Capacitance Accuracy, 0.1% Frequency Accuracy, -10 to 50 deg C, ABS, 167 mm L x 84 mm W x 46 mm D, Additional Information: 9 V Power Supply

Additional Information      :      9 V Power Supply
Amperage Rating      :      6 to 10 A
Battery Type      :      Alkaline
Capacitance Accuracy      :      1.9%, 5%
Capacitance      :      1000 nF to 1000 uF
Current Accuracy      :      1%, 1.5%
Dimensions      :      167 mm L x 84 mm W x 46 mm D
Display Type      :      Backlit LED
Frequency Accuracy      :      0.1 %
Frequency Rating      :      99.99 Hz to 50 MHz
Material      :      ABS
Measuring Range      :      2 V
Resistance Accuracy      :      0.9%, 1.5%
Resistance      :      600 Ohm to 40 MOhm
Temperature Rating      :      -10 to 50 deg C
Voltage Accuracy      :      0.5%, 1%, 2%
Voltage Rating      :      6 to 600 V
  • The large white LED backlight helps you work in poorly lit areas
  • VoltAlert technology gives you fact, go/no go non-contact voltage detection
  • Auto V and low input impedance modes provide faster, more accurate readings
  • VoltAlert technology for non-contact voltage detection
  • Auto V automatic AC/DC voltage selection
  • Low input impedance: helps prevent false readings due to ghost voltage
  • Large white LED backlight to work in poorly lit areas
  • True RMS for accurate measurements on non-linear loads
  • Measures 10 A (20 A overload for 30 sec)
  • Resistance, continuity, frequency and capacitance
  • Min/max/average with elapsed time to record signal fluctuations
  • Compact ergonomic design for one-handed operation
  • Compatible with optional magnetic hanger (ToolPak) for hands-free operation
  • 600 V maximum voltage between any terminal and earth ground
  • Surge protection - 6 kV peak per IEC 61010-1 600 V CAT III, pollution degree 2
  • 11 A , 1000 V fast fuse (Fluke p/n 803293)
  • 6000 counts digital display, updates 4/sec
  • 33 segments, updates 32/sec bar graph
  • 400 hr typical battery life without backlight
