Liberty Pumps® Submersible Sump Pump With Vertical Magnetic Float Switch, Series: 230, 115 VAC, 5.2 A, 60 Hz, 1/3 hp, 3450 rpm, 37 gpm at 5 ft Flow Rate, 1-1/2 in Discharge, 10 ft Cord Length, Maximum Feet of Head: 21 ft, 140 deg F Intermittent, 104 deg F Continuous Duty, Thermoplastic Impeller, Aluminum/Polypropylene, 10-1/2 in H x 9-3/5 in W, Powder-Coated
| Amperage Rating | : | 5.2 A |
| Cord Length | : | 10 ft |
| Dimensions | : | 10-1/2 in H x 9-3/5 in W |
| Discharge Size | : | 1-1/2 in |
| Finish | : | Powder-Coated |
| Flow Rate | : | 37 gpm at 5 ft |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1/3 hp |
| Impeller Material | : | Thermoplastic |
| Material | : | Aluminum/Polypropylene |
| Maximum Feet of Head | : | 21 ft |
| Series | : | 230 |
| Speed Rating | : | 3450 rpm |
| Temperature Rating | : | 140 deg F Intermittent, 104 deg F Continuous Duty |
| Voltage Rating | : | 115 VAC |
- Vortex style impeller permits passage of solids without clogging
- Stainless steel rotor shaft
- Non-corrosive stainless steel fasteners
- Oil filled, hermetically sealed motors with thermal overload protection
- Permanently lubricated upper and lower bearings
- Quick-connect 10 ft standard power cord allows replacement of cord in seconds without breaking seals to motor
- Lightweight, high performance submersible pump
- Vortex style impeller made of high temp engineered thermoplastic
- Powder-coated for corrosion resistance
- Anti-airlock hole allows trapped air to escape and the pump to prime and start pumping
- Removable base allows suction down to 1/8 in
Instruction/Installation Manual
Video Link
