TOTALINE® Outdoor Condenser Fan Motor, 1/3 hp HP Rating, 208 to 230 V, 2 A, 60 Hz, 1 ph, 1075 rpm Speed Rating, 1 Speed, Totally Enclosed Air Over, 48 Frame, 1/2 in Dia x 6 in L Shaft, Ball Bearing, Band, Bolt Mount, 140 deg F, Insulation Class: Class B, For Use With: Air Conditioners, Heat Pumps
| Amperage Rating | : | 2 A |
| Bearing Type | : | Ball |
| Enclosure Type | : | Totally Enclosed Air Over |
| Frame | : | 48 |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1/3 hp |
| Insulation Class | : | Class B |
| Mounting Type | : | Band, Bolt |
| Number of Speeds | : | 1 |
| Phase | : | 1 ph |
| Shaft Size | : | 1/2 in Dia x 6 in L |
| Speed Rating | : | 1075 rpm |
| Suitable For Use With | : | Air Conditioners, Heat Pumps |
| Temperature Rating | : | 140 deg F |
| Voltage Rating | : | 208 to 230 V |
- 5.6 in Dia, totally enclosed air over TEAO
- Extended studs
- 30 in leads
- Automatic reset thermal overload protector
- Continuous-duty
Specification Sheet
